Signage Solutions D-Line Display

65BDL4050D/00

Inform. Effortlessly

Make it clear with a powerful D-Line professional FHD display. This responsive solution offers brilliant picture quality, simple control, and reliable connectivity. Even in areas that are hard to network.

See all benefits

Signage Solutions D-Line Display

Similar products

See all D-Line series

Inform. Effortlessly

Smart, powerful 24/7 display.

  • 65"
  • Powered by Android
  • 450cd/m²
Operate, monitor and maintain with CMND & Control

Operate, monitor and maintain with CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

CMND & Create. Develop and launch your own content

CMND & Create. Develop and launch your own content

Take control of your content with CMND & Create. A drag-and-drop interface makes it simple to publish your own content-whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure your stills, text, and video will be up and running in no time.

FailOver ensures content is always playing

FailOver ensures content is always playing

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

Integrated HTML5 browser. Play and control online content

Integrated HTML5 browser. Play and control online content

Android SoC processor. Native and web apps

Control your display via an Internet connection. Android-powered Philips Professional Displays are optimized for native Android apps, and you can install web apps directly to the display too. A new Android OS ensures the software is kept secure and remain to the latest specification for longer.

CMND & Deploy. Install and launch apps remotely

Quickly install and launch any app-even when you're off-site and working remotely. CMND & Deploy lets you add and update your own apps, as well as apps from the Philips Professional Display App Store. Simply scan the QR code, log in to the store, and click on the app you want to install. The app is automatically downloaded and launched.

Integrated mPCIe slot for optional 4G/LTE module

Easily connect 4G/LTE modules to your Philips professional display. The integrated mPCIe slot enables your display to communicate with other devices that share the same wireless connectivity. Invaluable if you're installing displays in locations such as banks or government buildings, where you cannot get onto the local network.

Proof of Play for Android content. Know what's playing

Be sure your Android-powered Philips Professional Display is showing the right content-even when you're not there. When playing content via the embedded media player, you can set up your display to take automatic screenshots at regular intervals. Screenshots are stored on the display's internal memory, and you can choose to receive them via email.

Internal memory. Upload content for instant play

Save and play content without the need for a permanent external player. Your Philips professional display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.

Technical Specifications

  • Picture/Display

    Diagonal screen size (metric)
    166.37  cm
    Diagonal screen size (inch)
    65.5  inch
    Aspect ratio
    16:9
    Panel resolution
    1920x1080p
    Pixel pitch
    0.744 x 0.744 mm
    Optimum resolution
    1920 x 1080 @ 60Hz
    Brightness
    450  cd/m²
    Display colors
    16.7 million
    Contrast ratio (typical)
    1100:1
    Dynamic contrast ratio
    500,000:1
    Response time (typical)
    12  ms
    Viewing angle (horizontal)
    178  degree
    Viewing angle (vertical)
    178  degree
    Picture enhancement
    • 3/2 - 2/2 motion pull down
    • 3D Combfilter
    • Motion compens. deinterlacing
    • 3D MA deinterlacing
    • Dynamic contrast enhancement
    • Progressive scan
    Operating system
    Android 4.4.4
  • Connectivity

    Audio output
    • Audio Left/Right (RCA)
    • Ext. speaker cntrl (aud. out)
    Video input
    • DisplayPort (1.2)
    • HDMI (x2)
    • DVI-D
    • USB
    • VGA (via DVI)
    Audio input
    • 3.5 mm jack
    • Audio Left/Right (RCA)
    Other connections
    • mPCIe
    • micro SD
    • micro USB
    • USB power outlet (5 V. 2 amp)
    Video output
    • DisplayPort
    • DVI-I
    • VGA (via DVI-D)
    External control
    • RJ45
    • RS232C (in/out) 2.5 mm jack
    • IR (in/out) 3.5 mm jack
  • Convenience

    Placement
    • Landscape (24/7)
    • Portrait (24/7)
    Picture in picture
    PIP
    Tiled Matrix
    Up to 15 x 15
    Screen saving functions
    Pixel Shift, Low Bright
    Keyboard control
    • Hidden
    • Lockable
    Signal loop through
    • DVI
    • VGA
    • RS232
    • IR Loopthrough
    • DisplayPort
    Ease of installation
    Smart Insert
    Energy saving functions
    Smart Power
    Network controllable
    • RJ45
    • RS232
    • One Wire (HDMI-CEC)
    • HDMI (One Wire)
  • Sound

    Built-in speakers
    2 x 10W RMS
  • Power

    Consumption (EPA 6.0)
    99  W
    Mains power
    100 ~ 240 VAC, 50 ~ 60 Hz
    Consumption (Typical)
    103  W
    Standby power consumption
    <0.4 W
  • Supported Display Resolution

    Computer formats
    • 1920 x 1080, 60Hz
    • 1440 x 900, 60Hz
    • 1366 x 768, 60Hz
    • 1360 x 768, 60Hz
    • 1280 x 800, 60Hz
    • 1280 x 768, 60Hz
    • 1024 x 768, 60Hz
    • 800 x 600, 56, 60, 72, 75Hz
    • 640 x 480, 60, 67, 72, 75Hz
    Video formats
    • 1080p, 50, 60Hz
    • 1080i, 50, 60Hz
    • 720p, 50, 60Hz
    • 576i, 50Hz
    • 576p, 50Hz
    • 480p, 60Hz
    • 480i, 60Hz
  • Dimensions

    Smart Insert mount
    100 x 100 mm, 100 x 200 mm
    Set Width
    1452.0  mm
    Product weight
    29.8  kg
    Set Height
    833.1  mm
    Set Depth
    63.5  mm
    Set Width (inch)
    57.17  inch
    Set Height (inch)
    32.80  inch
    Wall Mount
    400 x 400, M6
    Set Depth (inch)
    2.50  inch
    Bezel width
    9.5 (T/L/R) 15.6 (B)
    Product weight (lb)
    65.7  lb
  • Operating conditions

    Altitude
    0 ~ 3000 m
    Temperature range (operation)
    0 ~ 40  °C
    MTBF
    50,000  hour(s)
    Relative humidity
    20 ~ 80  %
    Temperature range (storage)
    -20 ~ 60  °C
  • Multimedia Applications

    USB Playback Video
    • M2TS
    • M4V
    • MK3D
    • MKV
    • MP4
    • MPEG
    • MPG
    • MTS
    • TS
    • TTS
    • VOB
    • WMV
    USB Playback Picture
    • BMP
    • GIF
    • JPEG
    • JPG
    • PDF
    USB Playback Audio
    • AAC
    • AIF
    • AIFF
    • M4A
    • MP3
    • WAV
    • WMA
    • ASF
    • LPCM
    • M3U
    • MP4
  • Internal Player

    CPU
    Quad Core Cortex A9 1.8GHz
    GPU
    ARM Mali400 Quad Core 533MHz
    Memory
    2GB DDR3
    Storage
    16GB EMMC
  • Accessories

    Included accessories
    • Remote Control
    • Batteries for remote control
    • Quick start guide
    • RS232 cable
    • AC Power Cord
    Optional accessories
    ColourCalibrationKit (CCK4602)
    Stand
    Universal Stand(L)(BM05922)(Optional)
  • Miscellaneous

    On-Screen Display Languages
    • English
    • French
    • German
    • Spanish
    • Polish
    • Turkish
    • Russian
    • Italian
    • Simplified Chinese
    • Traditional Chinese
    • Arabic
    • Japanese
    • Danish
    • Dutch
    • Finnish
    • Norwegian
    • Portuguese
    • Swedish
    Warranty
    3 year warranty
    Regulatory approvals
    • EnergyStar 7.0
    • CE
    • FCC, Class B
    • UL/cUL
    • CCC
    • C-Tick
    • RoHS
    • GOST
    • BSMI
    • CB
    • J-Moss
    • PSE
    • VCCI

What's in the box?

Other items in the box

  • Remote Control
  • Batteries for remote control
  • Quick start guide
  • RS232 cable
  • AC Power Cord
  • Optional accessories: ColourCalibrationKit (CCK4602)
