Ultinon Drive 5050L

10 inch double row LED lightbar

UD5050LX1

Ultinon Drive 5050L 10 inch double row LED lightbar

UD5050LX1

Powerful brightness for a safer drive

Projecting light for 427m (boost: 448m), the Ultinon Drive 5050L LED lightbar is road-legal and provides a boost for offroad challenges. It ensures safety through brightness, is built to last, corrosion-free, resistant to water and shocks. See all benefits

Ultinon Drive 5050L 10 inch double row LED lightbar

Powerful brightness for a safer drive

Projecting light for 427m (boost: 448m), the Ultinon Drive 5050L LED lightbar is road-legal and provides a boost for offroad challenges. It ensures safety through brightness, is built to last, corrosion-free, resistant to water and shocks. See all benefits

Powerful brightness for a safer drive

Projecting light for 427m (boost: 448m), the Ultinon Drive 5050L LED lightbar is road-legal and provides a boost for offroad challenges. It ensures safety through brightness, is built to last, corrosion-free, resistant to water and shocks. See all benefits

Ultinon Drive 5050L 10 inch double row LED lightbar

Powerful brightness for a safer drive

Projecting light for 427m (boost: 448m), the Ultinon Drive 5050L LED lightbar is road-legal and provides a boost for offroad challenges. It ensures safety through brightness, is built to last, corrosion-free, resistant to water and shocks. See all benefits

Similar products

See all LED light bars

Powerful brightness for a safer drive

Bright, durable gear for overland journeys

  • Road-legal ECE R149-40
  • 3300 lm, 427m beam length
  • All-terrain, all-weather fit
  • Offroad boost function
Bright, long beam for superior visibility

Bright, long beam for superior visibility

The Philips Ultinon Drive 5050L provides an outstanding beam that illuminates the road ahead for 427 meters.* With 3300 lumen (effective) coming from its cumulated, powerful 100W LEDs and ECE-R149-40, it provides ample visibility for faster reactions. A combined spot and flood light, it shines both far and wide, helping you see roadside hazards too. The lamps' highly homogenous beam and cool light color of 6500 Kelvin keep you focused without straining your eyes.

Enhanced safety offroad with boost function for more power

Enhanced safety offroad with boost function for more power

The Philips Ultinon Drive 5050L is equipped with two light functions: for on-road drives, the lightbar brings you outstanding homologated brightness for greater safety. Offroad, you can opt for increased intensity. Switch on your boost function to unleash its full power and increase the beam length to 448 meters. More performance for tougher conditions.

Sturdy one-piece body for tough environments

Sturdy one-piece body for tough environments

The Philips Ultinon Drive 5000L series is built in a single piece to withstand the toughest conditions. This allows for excellent heat management and consistently high light output throughout your journey. Rated IK07, it is shock-resitant to ensure faultless performance on and off the road. Its unbreakable polycarbonate lens can take any hit without damage or scratches and the convenient DT connector guarantees a perfect connection.

IP69K waterproof to master the elements

IP69K waterproof to master the elements

With its ingenious screwless design, the Ultinon Drive 5000L series can withstand the wettest conditions. IP68 and IP69K certification means it will perform, wherever your road leads and whatever the weather. And it will be more than a match for any power washer you use to clean your car afterwards.

Powerful road-legal LED lightbars

Powerful road-legal LED lightbars

The Philips Ultinon Drive 5000L series meets ECE-R149 standards and is road-legal. For added safety, Philips LED lightbars are tested to EMC R10 specification to ensure they will function smoothly with your vehicle's electrical systems.

Corrosion-free, stainless-steel mounting brackets

The mounting backets are made of stainless steel, which is corrosion-free. They can withstand snow, ice and even salt. Built from durable, high-quality materials, your auxiliary lights will provide years of reliable service.

Technical Specifications

  • Product description

    Boost mode activation
    Dashboard switch
    Break resistance
    Yes
    Corrosion-free brackets
    Yes, included
    ECE R10
    Yes
    ECE R149
    Yes
    ECE reference number
    40
    Heat sink
    13-piece 1.5mm
    Impact protection rating (IK)
    IK07
    Ingress protection rating (IP)
    IP68 & IP69K
    Installation angle
    360°
    Material
    Aluminum die-cast
    Number of LEDs
    20x 5W
    Offroad boost
    Yes
    One-piece body design
    Yes
    Operating temperature
    -40° C to 80° C
    Plug type
    Connector with 0.5m cable
    Range
    Ultinon Drive 5000
    Scratch resistant lens
    Yes
    Technology
    LED
    Width
    10 inch
    Boost function installation
    Cable included
  • Light characteristics

    Color temperature
    6500 K  K
    Beam length 3 lux-m
    245
    Beam length 1 lux-m
    425
    Beam width 3 lux-m
    64
    Beam width 1 lux-m
    90
    Beam length 3 lux (boost)-m
    258
    Beam length 1 lux (boost)-m
    448
    Effective lumen output
    3300
    Raw lumen output
    9520
    Effective lumen output (boost)
    4000
  • Electrical characteristics

    Voltage
    9-30 Volt DC
  • Ordering information

    Order entry
    UD5050LX1
    GOC
    01493194
  • Packaging Data

    EAN1
    8719018014931
    EAN3
    8719018014924
  • Packed product information

    MOQ (for professionals)
    4
    Dimensions-L(mm)
    339
    Dimensions-W(mm)
    49.3
    Dimensions-H(mm)
    84.2
    Box dimensions-L(mm)
    350
    Box dimensions-W(mm)
    90
    Box dimensions-H(mm)
    105
    Net weight product-g
    1010
    Gross weight box-g
    1020

Suggested products

Recently viewed products

  • Beam length measured on 1 lux.
