Ultinon Drive 5100

4 inch LED light bar

LUMUD5101LX1

Ultinon Drive 5100 4 inch LED light bar

LUMUD5101LX1

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're headed. Spot hazards up to 240 meters away with lighting that peforms in the most hostile environments and gives your vehicle a touch of style. See all benefits

Ultinon Drive 5100 4 inch LED light bar

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're headed. Spot hazards up to 240 meters away with lighting that peforms in the most hostile environments and gives your vehicle a touch of style. See all benefits

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're headed. Spot hazards up to 240 meters away with lighting that peforms in the most hostile environments and gives your vehicle a touch of style. See all benefits

Ultinon Drive 5100 4 inch LED light bar

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're headed. Spot hazards up to 240 meters away with lighting that peforms in the most hostile environments and gives your vehicle a touch of style. See all benefits

Similar products

See all LED lightbars

Powerful brightness driving safety at the wheel

Bright, durable gear for overland journeys

  • Road-legal ECE R149-12,5
  • 1150 lm, 240 m beam length
  • Dual-color position light
  • All terrain, all weather

Intense, far and wide illumination for superior visibility

The Philips Ultinon Drive 5101L LED light bar provides a brilliant light beam that illuminates the road ahead for up to 240 meters*. Its effective 1150 lumens are homogeneously distributed in an optimized indirect beam, generating intense illumination far and wide with reduced glare for everyday use. This enables drivers to react faster on dark, rural and dirt roads. Its cool light color of 6500 Kelvin produces daylight conditions, improving contrast and helping drivers stay focused.

Choose your position-light color

Never go unnoticed on side roads or in parking areas with the extra LED position lights of our Philips Ultinon Drive 5101L. Express your style and personality by choosing your light color, either intense amber or cool white.

IP68 & IP69K-rated to master the elements

With its ingenious screwless design, the Philips Ultinon Drive 5101L LED light bar can withstand the wettest conditions. Its IP69K certification means it will perform, wherever your road leads and whatever the weather. And it will be more than a match for any power washer you use to clean your car afterwards.

Corrosion-free body, stainless-steel mounting brackets

With its anodised pre-treated and automotive-grade powder-top-coat body, the Philips Ultinon Drive 5101L LED light bar offers ultimate corrosion protection. Its mounting brackets are made of stainless steel, which is corrosion-free. It can withstand snow, ice and even salt. Built from durable, high-quality materials, your Philips auxiliary LED lights will provide years of reliable service.

Powerful road-legal LED lightbars

The Philips Ultinon Drive 5101L LED light bar meets ECE standards and is 100% road-legal for high-beam and position-light functions. For added safety, Philips LED light bars are tested to EMC R10 specification to ensure they will function smoothly with your vehicle's electrical systems.The Philips Ultinon Drive 5101L LED light bar meets ECE standards and is 100% road-legal for high-beam and position-light functions. For added safety, Philips LED light bars are tested to EMC R10 specification to ensure they will function smoothly with your vehicle's electrical systems.

Low-profile design for simpler fitment

The sleek, low-profile design makes installation easier, and flexible fitment options are possible with side-mounting brackets (included) and back-mounting brackets (UD1001M optional). Supplied with a pre-wired male/female 3-pin superseal DT connector, it is voltage-overload and reverse-polarity protected to make installation secure and easy.

Technical Specifications

  • Electrical characteristics

    Voltage
    9-30 Volt DC
  • Product description

    Accessories (optional)
    LUMUD1001M, LUMUD1003W, LUMUD1004W
    Boost function installation
    No
    Boost mode activation
    No
    Break resistance
    Yes
    corrosion-free brackets
    U shape mounting bracket
    ECE R10
    Yes
    ECE R148
    Yes
    ECE R149
    Yes
    ECE reference number
    12.5
    Impact protection rating (IK)
    IK07
    Ingress protection rating (IP)
    IP68 & IP69K
    Installation angle
    360°
    Material
    Aluminum extruded
    Offroad boost
    No
    One-piece body design
    Yes
    Operating temperature
    -40° C to 80° C
    Parking position light
    Yes, white or amber
    Range
    Ultinon Drive 51000
    Plug type
    4-pin DT Connector with 0.5m cable
    Scratch resistant lens
    Yes
    Technology
    LED
    Width
    150 mm / 4  inch
  • Light characteristics

    Beam length 1 lux-m
    240
    Color temperature
    6500 K  K
    Effective lumen output
    1150 lumens
    Raw lumen output
    4950 lumens
  • Packed product information

    Box dimensions-L(mm)
    350
    Box dimensions-W(mm)
    90
    Box dimensions-H(mm)
    90
    MOQ (for professionals)
    8
    Number of product in the box
    1 lamp
  • Ordering information

    GOC
    01842750
    Order entry
    UD5101LX1
  • Packaging Data

    EAN1
    8719018018427
    EAN3
    8719018018434
  • Outerpack information

    Height
    200  cm
    Length
    370  cm
    Width
    200  cm

Suggested products

Recently viewed products

  • Beam length measured on 1 lux.
